10.1inch 4CH Vehicle Monitor with 4G GPS WIFI Function And USB Connection TFT IPS Screen 1-Year Warranty

10.1inch 4CH Vehicle Monitor with 4G GPS WIFI Function And USB Connection TFT IPS Screen 1-Year Warranty

The 10.1-inch 4CH split monitor is a versatile surveillance device designed for reliable and efficient monitoring. It features a Hi3521A chipset and runs on Linux, supporting H.264 compression for high-quality video recording. With 4-channel AHD video input, it can display multiple camera feeds simultaneously. The monitor supports up to 1TB SD card storage, power-on and timing recording options, and offers a wide operating temperature range (-30℃ to +70℃). Optional GPS, 4G, and Wi-Fi connectivity enhance its functionality. Compact and durable, it is ideal for fleet management, security surveillance, and mobile monitoring applications.

Quantity:
Availability:





Inquire Add to Basket

Model:
SMT838-10.1SD

Core Features of 10.1inch AHD MDVR Monitor

1. High-Resolution Display with Multi-Resolution Support

Equipped with a 10.1-inch HD screen, the monitor supports multiple resolutions (1920×1080, 1280×720, 1024×768, 800×600) for clear and detailed image display. It also accepts 4CH AHD (1080P/960P/720P) and CVBS (D1, 960H) video inputs, ensuring compatibility with a wide range of cameras.

2. Efficient Storage and Flexible Recording Options

The monitor supports up to 1TB SD card storage, providing ample space for extended surveillance. It offers power-on recording and timing recording options, allowing users to customize their monitoring needs.

3. Wide Voltage Input and Reliable Performance

With an input voltage range of DC12-36V, the monitor is compatible with various vehicle power sources. It operates reliably in extreme temperatures (-30℃ to +70℃) and features power-off memory protection to ensure data safety.

4. Optional Wireless Connectivity and Smart Expansion

The monitor supports optional GPS, 4G, and Wi-Fi functions for remote monitoring and data transmission. It also offers multiple extension cable options (3m, 5m, 10m, 15m) to meet different installation requirements.

5. Multiple Trigger and Display Modes

It features 3 groups of I/O trigger inputs, compatible with 12-24V power supply triggers for full-screen display. The monitor also supports various display modes, including quad-view and single-channel full-screen display, to suit different scenarios.

These advantages make the 10.1-inch 4CH split monitor an ideal choice for vehicle surveillance, security monitoring applications.

Scenes Solutions

Application: Buses, School Bus,Freigt Truck,RV,Ship & Crane,Forklifts,Emergency & Rescue,Tax,Rail Transit,Agricultual Vehicles,etc.

Truck

School Bus

bus monitor

Taxi

Excavator

Forklift

Bus

Emergency & Rescue

Specification

Item		Parameter
Plan		HiSilicon hi3520(V300)
System language		Chinese, Traditional Chinese, English, Other (customizable)
Video compression format		H.264
OSD		Character overlay function, supports time and date, channel characters, segmentation borders, vehicle information and other image overlays
Video and recording system	Video input	4CH AHD1080P/960P/720P and 960H, D1 (CVBS) and other video inputs; 2CH HD + 2CH SD, 3CHHD + 1CH SD, 1CH HD + 3CH SD video inputs; Compatible with CVBS and AHD signal mixed input; Compatible with PAL and NTSC mixed input;
	Preview function	12 kinds of multi-screen mode splicing preview, support manual/voltage trigger full screen display function
	Resolution	19201080, 1280720, 1024768800600
	Video resolution	1920*1080
	Video image quality	Ultra-HD, HD, standard, ordinary 4-level video recording adjustable
	Recording method	Automatic recording when powered on
Audio	Audio input	Support 1CH audio input (CH1 interface) (optional)
	Audio output	Not support
	Compression format	G.726
Trigger input		3 groups of I/O triggers, support 12-24V power supply to trigger full screen display
Memory card	SD card	Support 2-512G memory card, automatic deletion when full, cyclic overwriting
	Upgrade method	Support SD video card upgrade
	Storage method	Proprietary raw disk storage method: real-time storage, without missing a second
	USB	Recording/upgrade/backup
Video playback	Video search	You can choose the last three days, last week, last two weeks, last month, all, etc.
	Playback	4CH synchronous playback, support pause, fast forward and fast rewind
	Playback	Support 2, 4, 8 times fast forward or rewind
Power supply &consumption	Power management	Adaptive wide power input, with protection functions such as low voltage, over voltage, reverse connection and short circuit
	Input voltage	DC: +12V ~ +36V (camera operation requires input voltage above 13V)
	Output voltage	+11.5V/3A
	Consumption	Normal working state <5W (excluding display screen and camera)
Working environment	Temperature	-30℃ to +70℃
Working environment	Humidity	20% to 80%

About Seemetech

Founded in 2017, Seemetech is a dynamic technology company dedicated to delivering innovative solutions in the field of intelligent transportation and vehicle security. With a strong focus on R&D, we specialize in designing and manufacturing cutting-edge products such as MDVR (Mobile Digital Video Recorders), MNVR (Mobile Network Video Recorders), and Car Monitors, empowering businesses worldwide to enhance safety, efficiency, and operational control.

Our Core Products

MDVR & MNVR: Advanced in-vehicle surveillance systems tailored for real time monitoring, GPS tracking and data analytics. Ideal for fleet management，public transportation，and logistics.
Car Monitors：High performance displays designed for seamless integration with vehicle systems，ensuring clear visibility and user friendly interfaces for drivers and operators.

Technology & Innovation

At Seemetech, we pride ourselves on our 20-member R&D team—a passionate group of engineers and industry experts committed to pushing technological boundaries. By leveraging AI, IoT, and cloud-based platforms, we continuously refine our products to meet evolving market demands.
Our Mission

We strive to redefine vehicle safety and connectivity through intelligent solutions that bridge the gap between technology and practicality. By partnering with global clients, we aim to drive progress in smart transportation ecosystems and deliver unparalleled value to industries worldwide.
Our Vision

As we expand our global footprint, Seemetech remains steadfast in its commitment to innovation, customer-centricity, and sustainable growth. Join us in shaping the future of mobility.

FAQs

Do you support OEM and ODM services?

Yes,we support OEM and ODM services. We have a professional R&D team to support various customization.
Are you a manufacturer factory or a trading company?

We are the original manufacturer located in Shenzhen,China, which has rich experience in car monitors ,car cameras and car players , warmly welcome to visit our factory.
How do you guarantee product quality?

All goods are 100% inspected before shipping, we do at least 5 tests, including In-coming raw material test, sample test then bulk produce, functional test, burn-in test, appearance inspection.
How to place an order?

1.Choose the product you like, confirm the model and quantity and place the order on Alibaba directly.
2. Tell us your special request and then we will recommend the right items accordingly ,and match them together for you then.
What's the MOQ for products?

MOQ no limited, sample orders also welcomed.
What's the payment terms?

T/T, PayPal, Ali pay,etc.
For sample orders, 100% in advance, for bulk orders 30% or 50% deposit, the balance before shipment.
What are the shipping method?

By express(DHL,Fedex, UPS), by sea, by air, or other available shipping methods appointed by customers, provide tracking number and estimated time of arrival.
What's the lead time?

1. Sample order 1 to 5 PCS: 3-7 working days.
2. General order 100 to200PCS: 7-15 working days.
3. Bulk order 500 to 1000PCS: 15-30 working days.(All depends on the quantity)
What after-sales support is available?

All products have one year warranty and we have professional technical support. If you have any problems with the product, we will provide solutions at any time.
