10.1 Inch 4CH AHD Recorder 1080P DVR Car Monitor Vehicle Truck Night Vision Rear View Camera Support SD Card Recording

This is a MDVR monitor system with four cameras installed around the car, Which can record real-time video around the car. The driver have a wide view of special road, and it can be used for accident evidence collection and safeguard the legitimate rights of the driver. The driver can provide effective for himself. At the same time, the following problems can be effectively solved: Vehicle monitoring ,disputes over accidents ,parking difficulties, difficulties in reversing,complicated road conditions,blind spots in driving , no one watching the car, etc.
Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
kakao sharing button
snapchat sharing button
telegram sharing button
sharethis sharing button
  • SMT1001

Core Features of 1080P AHD 4CH MONITOR DVR

Key Features of 1080P AHD 4CH MONITOR DVR

1. support mixed input of AHD 1080P/ AHD 720P/ 960H/ CVBS in multiple video formats;


2. PAL/NTSC mixed input of different formats supporting AHD/ CVBS video signals (adaptive)


3. Brightness, contrast, saturation, chroma and sharpness can be independently set for each input video signal;  The (left-right) mirror image function and the up-down flip function can be independently set


4. Video output, you can set up the zoom display of the upper, lower, left and right margins, so that different display screens on the market can be displayed full and the picture will not be cut and deleted


5. Support parking stall delay video recording (24-hour parking monitoring function)


6. Maximum support SD/USB 512G memory card, super-long panoramic image memory, convenient for users to consult at any time


7. Independent four-way display function, automatically switching display screen when turning and reversing


8. Panoramic monitoring and recording image controllable playback function is convenient for real-time viewing


9. Users of this system can upgrade the latest programs through video cards

Scenes Solutions

Application: Buses, School Bus,Freigt Truck,RV,Ship & Crane,Forklifts,Emergency & Rescue,Tax,Rail Transit,Agricultual Vehicles,etc.

Freigt Truck

Freigt Truck

school bus

School Bus

RV

RV

taxi

Taxi

Rail Transit

Rail Transit

forklift

Forklift

bus

Bus

Emergency&Rescue

Emergency & Rescue

Specification

Name

parameter

Name

parameter

Input signals

CVBS,960H,AHD720P,AHD1080P

Output signals

40pin-LVDS or pin-TTL

Output system

PAL,NTSC Optional

resolution

1920*1080

Format

H.264

Storage

capacity external TF card maximum support   512GB (circular overlay)

Start Time

11 Seconds

Software update

Video Card Update

Working voltage

12V -36V (minimum   input 13V for camera to draw power from mainboard)

trigger voltage

12V-24V

Operating current

12V/450mA (excluding display screen and   camera)

Operating temperature

-30℃~+70℃
